Prefabricated large-span intelligent steel structure farm breeding building

Prefabricated large-span intelligent steel structure farm breeding building

Steel structure livestock farming buildings are efficient facilities that meet the needs of modern large-scale farming. With steel as the main structural material, they combine and flexibility. The skeleton is composed of steel columns, steel beams and other components, with strong load-bearing capacity, which can easily support the weight of the top cover, and farming equipment. Moreover, they have excellent wind and earthquake resistance, which can resist the impact of bad weather on the farming environment.

The internal space is designed flexibly. can be divided into functional areas such as feeding area, feeding area and manure treatment area according to the different livestock species (such as pigs, cattle, poultry, etc.) In combination with adjustable partitions and ventilation systems, it can precisely control environmental parameters such as temperature and humidity, and provide suitable growth conditions for livestock and poultry. The walls and roofs adopt composite boards with good thermal insulation performance, which not only reduces the influence of temperature fluctuation outside the farming area, but also facilitates cleaning and disinfection, and reduces the risk disease transmission.

​

1.Product name	Cheap steel structure farm building
2.Application	Broiler house, layer house, breeding house, brood house etc
3.Frame type	Portal frame or steel roof truss
4.Main steel frame	H beam or square pipe with anti-rust paint or hot dip galvanized
5.Roof &cladding	75mm Glass wool sandwich panel composite on site
6.Door	Special insulation door for poultry house
7.Window	Plastic steel sliding window
8.Brick wall	300mm,500mm,800mm



The steel structure farm breaks the traditional agricultural building pattern, uses Q355B low-alloy high-strength steel to build the skeleton, and builds a column-free shed with large span and high space with the characteristics of high strength and light weight, which not only provides ample space for large-scale agricultural machinery operations and large-scale breeding, but also can be flexibly separated into planting area, breeding area and processing and storage area. The standardized steel components prefabricated in the factory are quickly assembled on site, which shortens the construction period by nearly half, reduces the generation of construction waste, and practices the concept of green construction. The surface of the steel is treated with hot-dip galvanizing and anti-corrosion coating, which can effectively resist the erosion of acid, alkali and moisture in the agricultural environment and prolong the service life; Combined with the windproof and earthquake-resistant design, it can calmly cope with extreme weather and build a solid safety barrier for crops and livestock.

Product Advantages:

1. Strength and Load-Bearing Capacity for Agricultural Needs
Steel, by itself, has extremely highile, compressive, and shear strength. Under the same cross-sectional size, the load-bearing capacity of steel structures far surpasses that of traditional masonry or structures. This allows steel structure farm buildings to easily handle a variety of load requirements in agricultural production, ensuring the integrity of the internal space for the free passage and operation of agricultural machinery and also efficiently supporting the stacking of heavy objects such as silage feed and agricultural equipment, avoiding structural deformation or damage caused by excessive load.

2. Ductility andismic Performance for Structural Safety
Steel structures have good ductility, which allows them to absorb energy through their own deformation when subjected to external force impact or vibration. agricultural production, extreme weather (such as strong winds, earthquakes) or unexpected collisions (such as scratches during the operation of agricultural machinery) may occur, and the ductility of steel can effectively reduce the risk of damage to the building structure. In earthquake-prone areas, steel structure farm buildings can better withstand the impact of seismic waves, reducing losses such as and poultry casualties and equipment damage caused by building collapse, and providing more reliable safety protection for agricultural production.

3. Lightweight Characteristics Reduce Construction and Foundation Costs
pared with masonry, concrete and other materials, although steel has a high density, due to its high strength characteristics, the cross-sectional size of steel structures is smaller the self-weight is lighter under the same load requirements. This lightweight characteristic brings many advantages: on the one hand, it reduces the load requirements for the building foundation, reduces amount of materials and construction difficulty of the foundation project, and thus reduces the overall construction cost; on the other hand, the light weight makes the transportation and hoisting of steel structure more convenient, shortening the construction cycle, especially suitable for farms and other scenarios with certain construction progress requirements.

4. Durability and Corrosion Resistance for Farm EnvironmentThe farm environment is often complex, and there may be ammonia gas from livestock and poultry manure, humid air, and moisture from irrigation water, etc., which can easily corrosion to the building structure. High-quality steel structures can significantly improve their corrosion resistance and enhance the durability of the structure by adopting treatment methods such as galvanizing and applying-corrosive coatings. Compared with wooden structures, steel structures are not prone to decay and deformation due to dampness; compared with masonry structures, they have better and are not prone to cracks, peeling and other issues due to long-term exposure to humid environments, thereby extending the service life of farm buildings and reducing the cost of maintenance

What we can offer you

Preliminary consultation and planning: The steel structure company will send a professional team to have an in-depth understanding of the farmer's production plan, breeding or planting types and budgets. According to the climatic conditions, topography and landform of the farm, provide site selection suggestions, and plan the layout of the farm in combination with the characteristics of the steel structure, such as determining the location of different functional areas such as breeding area, planting area, storage area, etc., to ensure that the connection between the areas is reasonable and improve production efficiency.

Design customization: Experienced structural engineers and architectural designers will tailor the design scheme of the steel structure farm according to the preliminary planning. Accurately calculate the amount of steel and the force on the structure to ensure that the steel structure has sufficient strength and stability while meeting the requirements of large-span space. In the design process, the individual needs of the farm are fully considered, such as designing appropriate ventilation, lighting and temperature control systems according to the habits of different breeding animals; For planting areas, design a reasonable location for the installation of irrigation and shading facilities.

Material supply and quality control: With long-term cooperative relations with high-quality steel suppliers, we provide high-quality steel for farm projects, such as main structural materials such as H-beam and channel steel, as well as enclosure materials such as color steel plates and insulation materials. Strictly control the quality of each batch of materials, test the strength, toughness and other key properties of steel to ensure that the materials meet the design requirements and relevant standards, and ensure the quality of the steel structure farm from the source.

Construction: The professional construction team is proficient in the steel structure construction technology, and the steel structure components are prefabricated with high precision in the factory to ensure that the components are accurate in size and stable in quality. After being transported to the site, it will be assembled in an orderly manner according to the construction plan, and the steel structure will be built quickly and safely through welding, bolting, etc. During the construction process, we strictly follow the safety specifications and quality standards, control every construction link, and ensure that the project is delivered on time and with high quality.

Company Profile

China CT Steel Structure Co.,Ltd of BY GROUP is a comprehensive industrial group integrating for steel structure design, manufacture and installation. We have estabulished over 15 years. Our factory is covering about106,5 60 square meters.

Main products: steel structural warehouse, workshop, high rise steel building, school, hotel,office building, exhibition building, show room, shopping mall, stadium,Agricultural project (stable/cattle barn, poultry house,pig house), car parking, hangar,shed,storage room, prefab house, container house, Sandwich panel,corrugated steel sheet, C&Z sec- tion steel, door and windows and cranes.
